ABB – 1SDA067417R1 – Electromechanical Circuit Breakers – ICDC-040317 – New Main Category: Electromechanical | Sub-Category: Circuit Breakers | Status: New Original Components ABB Part Number: 1SDA067417R1 | ICDC Internal Part Number: ICDC-040317 1SDA067417R1 Description: XT1N 160 TMD 125-1250 3p F F General Information Extended Product Type:XT1N 160 TMD 125-1250 3p F F Product ID:1SDA067417R1 EAN:8015644013110 Catalog XT1N 160 TMD 125-1250 3p F F C.BREAKER TMAX XT1N 160 FIXED THREE-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMD R 125-1250 A Categories Products » Low Voltage Products and Systems » Circuit Breakers » Moulded Case Circuit Breakers » Tmax XT Ordering E-Number (Finland):3640520 E-Number (Sweden):3182428 EAN:8015644013110 Minimum Order Quantity:1 piece Customs Tariff Number:85362090 Dimensions Product Net Width:76.2 mm Product Net Height:130 mm Product Net Depth / Length:70 mm Product Net Weight:1.085 kg Container Information Package Level 1 Units:box 1 piece Package Level 1 Width:128 mm Package Level 1 Height:135 mm Package Level 1 Depth / Length:143 mm Package Level 1 Gross Weight:1.141 kg Package Level 1 EAN:8015644013110 Environmental RoHS Status:Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 Additional Information Circuit Breaker Type to be Associated:Power Distribution Current Type:AC/DC Electrical Durability:120 cycles per hour 8000 cycle Mechanical Durability:240 cycles per hour 25000 cycle Number of Poles:3 Opening Time:CB with SOR 15 ms CB with UVR 15 ms Order Multiple:1 piece Power Loss:at Rated Operating Conditions per Pole 10.7 W Product Main Type:SACE Tmax XT Product Name:Moulded Case Circuit Breaker Product Type:CB Rated Current (In):125 A Rated Frequency (f):50 / 60 Hz Rated Voltage (Ur):690 V Rated Impulse Withstand Voltage (Uimp):8 kV Rated Instantaneous Short-Circuit Current Setting (Ii):1250 A Rated Insulation Voltage (Ui):800 V Rated Operational Voltage:690 V AC 500 V DC Rated Service Short-Circuit Breaking Capacity (Ics):(220 V AC) 50 kA (230 V AC) 50 kA (240 V AC) 50 kA (380 V AC) 36 kA (415 V AC) 36 kA (440 V AC) 18 kA (500 V AC) 15 kA (525 V AC) 11 kA (690 V AC) 5 kA (250 V DC) 2 Poles in Series 36 kA (500 V DC) 3 Poles in Series 36 kA Rated Ultimate Short-Circuit Breaking Capacity (Icu):(220 V AC) 65 kA (230 V AC) 65 kA (240 V AC) 65 kA (380 V AC) 36 kA (415 V AC) 36 kA (440 V AC) 36 kA (500 V AC) 30 kA (525 V AC) 22 kA (690 V AC) 6 kA (250 V DC) 2 Poles in Series 36 kA (500 V DC) 3 Poles in Series 36 kA Rated Uninterrupted Current (Iu):160 A Release:TMD Release Type:TM RoHS Date:NA Setting Range:87.5…125 A Short-Circuit Performance Level:N Standards:IEC Sub-type:XT1 Terminal Connection Type:Fixed Circuit-Breakers Version:F CAD Dimensional Drawing:1SDH001295R0008 Certificates and Declarations (Document Number) Data Sheet, Technical Information:1SDC210100D0206 1SDC210099D0206 Declaration of Conformity – CE:9AKK106713A5532 Environmental Information:9AKK107991A8215 GL Certificate:1SDL000163R0103 Instructions and Manuals:1SDH000719R0001 LR Certificate:1SDL000163R0100 REACH Declaration:9AKK108466A1425 RoHS Information:9AKK108466A1424 VDE Certificate:No certification needed Mechanical Drawings:1SDH000719R0100 Wiring Diagram:1SDM000068R0001 Classifications ETIM 4:EC000228 – Power circuit-breaker for trafo/generator/installation prot. ETIM 5:EC000228 – Power circuit-breaker for trafo/generator/installation prot. ETIM 6:EC000228 – Power circuit-breaker for trafo/generator/installation prot. ETIM 7:EC000228 – Power circuit-breaker for trafo/generator/installation protection ETIM 8:EC000228 – Power circuit-breaker for trafo/generator/installation protection Object Classification Code:Q UNSPSC:39120000 WEEE Category:5. Small Equipment (No External Dimension More Than 50 cm) eClass:V11.1 : 27370409 Contact us to discover 1SDA067417R1. ICDCSPARES.COM offers new or overhauled original components, ready in stock to be shipped via DHL Express! Call us! Check our Electromechanical section to discover more about ICDC catalog: a large selection of industrial spare parts including Fuses, Electric Motors, Switches and Circuit Breakers. Are you looking for industrial Circuit Breakers? ICDC offers online a wide selection of Circuit Breakers of the most important OEMs like EATON, ABB and DANFOSS, besides ABB. ICDC, Your Industrial One Stop Shop for Components!
